EG-NEXT-TOPMILK

The NEXT Top Milk is controlled by a 10.1” HD tablet interface, with a f lexible and customizable operating system powered by Android™. Two self-adjusting grinders make precise adjustments to the grind setting for consistent taste and volume in each cup, on each machine, and at each location. The NEXT Fridge allows for top-quality milk drinks to be dispensed automatically. The NEXT is made of stainless steel and ABS plastic and features an easy 3-step automatic daily cleaning program.

Standard Features

• Super automatic with app-controlled user interface

• HD tablet interface powered by Android™

• Single milk pump system

• Dual Ditting® Self-Adjusting grinders automatically adjust grind size to compensate for environmental changes

• NEXT countertop fridge (6.5L/1.7 gal) fits perfectly on the left side of the machine

• Americano bypass enables the machine to deliver authentic Americanos into a single cup

• Lowest cost of ownership of any fully automatic

• Premium espresso brewing

• Centralized hot water

• Patented stainless steel 18-gram brew group

• Made of stainless steel and ABS plastic

• 2-year parts warranty

Options

• iSteam: Intelligent steam wand automatically froths or steams milk, and shuts off at programmed temperature

• Automatic Spout+: Automatically adjusts the dispensing spout to the correct cup size

• Under Counter Grounds Chute: Chute that diverts ground coffee to under the counter waste container (not available when fridge is installed directly under the machine)

• External Hot Water Outlet: Hot water delivered through a separate outlet to the right of the drink spout

• Self-Service Package: Includes locks for hopper, grounds drawer, and fridge, as well as cup stopper pins for the drink tray

• Powder Module: Enables machine to deliver up to 2 types of powder, such as chocolate for mochas and for hot chocolate (not available w/ Cool Coffee Module)

• Cool Coffee Module: Rapidly cools coffee after brewing for the best quality iced beverages (not available w/ Powder Module)

• BC22: High-capacity 25-gram brew chamber allows for extra-large coffee drinks to be prepared in a single brew cycle

• Multi-Milk: Add to any fridge configuration to deliver two types of milk

• Cold Milk Foam: Delivers amazingly stable cold foam for unique drinks (not available with Multi-Milk or any undercounter configuration)

Accessories in the Box

• Plastic grounds bin container

• One-month supply of daily cleaning products

• Milk container

• Container for daily cleaning

• User manual

• Foot extensions

Fridge Features

• Fits next to the machine or undercounter, and automatically pumps milk into the machine. Includes a milk container that maximizes milk storage capacity and contains a milk level sensor

Space Requirements

• Allow at least one and a half inches (1.5”) of clearance from the back of the machine to the nearest wall for air circulation.

• Allow at least four inches (4”) of clearance above hoppers to refill. (recommended 12”)

• Allow 24” x 5” for in-line filters. Filter can be mounted behind the machine or under the counter.

Electrical Connections

1. Espresso Machine

• Voltage Range: 208-240VAC

• Power: 6000W Circuit Size: 30A

• Suggest Receptacle: NEMA L6-30R

2. Countertop Fridge/Powder Module (optional)

• Voltage Range: 110-120VAC

• Power: 200W

• Circuit Size: 15A

• Suggest Receptacle: 5-15R GFI

NOTE: Egro machines do not use a neutral line. A dedicated ground wire is required. Power can be installed under or above the counter. Please allow 3.5”-4” of space for the plug, especially when placing power above the counter and behind the machine.

Water Connections

• Dedicated cold water access line with standard female 3/8” NPT fitting and manual shut-off valve within 4’ of the machine required.

Drain Requirements

• Open gravity drain with minimum 2” I.D. within 4’ of the machine.

Water Quality Statement

• The fact that water is potable is no guarantee that it is suitable for coffee machines. Your water supply must be within these general guidelines:

• Supply Pressure: 30-70 psi

• Hardness: 2-3 GPG (1 grain of hardness = 17.1 ppm)

• Water entering the machine should have a water hardness level of 2-3 GPG at all times. If the water supply is not within this range, a dedicated water softener (if above 3 GPG) or mineral addition cartridge (if below 2 GPG) is required for the coffee machine to operate properly over time

Countertop Requirements

1. Espresso Machine w/ Fridge

• Width: 24”

• Depth: 23”

• Height: 31”

• Weight: 190 lbs

2. Espresso Machine w/ Fridge and Powder Module

• Width: 30”

• Depth: 23”

• Height: 31”

• Weight: 218 lbs
